Price: $129.99
(as of Jun 16, 2023 22:12:22 UTC – Details)
Feature
10,000 PSI air/hydraulic foot pump requires 100-150 PSI air pressure
Designed to be used with single acting cylinders
Provides hands free operation for pumping and releasing load
Usable fluid capacity 9/20 gal
Flow rate 42 cu. in. with no load, 8.5 cu. in. with load
1 Years Warranty on material and workmanship
Complies with ASME PALD/2009 Safety Standards
Fast Acting With 1700cc Oil Reservoir
For Use On Ram Cylinders From 10 Ton Capacity
Includes 5 Foot High Pressure 700 Bar (10,000 Psi) Hose And Coupler
Includes 4 Foot Compressed Air Line With Air Control
Specifications
Input Air Pressure: 100-150Psi（7-10.5bar）
Max.Out Put Pressure: 10000Psi（70bar）
Max. Output Flow Rate: 9/20 Gal（104cu.in）
Air Port Threads: 1/4”NPT
Oil Port Threads: 3/8”NPT
Max. Output Flow Rate NO LOAD: 850ml/min（52cu.in）
Max. Output Flow Rate (in3/min) LOAD: 170ml/min（10cu.in）
Air consumption（under 100psi/6.9bar）: 11 SCFM（0.31 cu.m/min)
Product Description
Our piston can be opened to access and change the seal inside. Plastic pistons are factory sealed and can only be replaced. We now use TEFLON SEALS on the piston they last longer perform better and withstand the heat very well.
Aluminum Piston Sleeve:
So many of these pumps are using steel metal piston sleeves & as you know compressed air carries water in it. The water in the air will corrode this sleeve, tear the seals, and seize the piston. This sleeve corrosion renders the pump dead as the cost to replace (If it is even available as a part) is very high. Our pump has an aluminum sleeve with a proprietary anti corrosion coating. Although excessive water will ruin any pump our sleeve will last a very long time.
Metal air vent:
As the pump pushes oil out it must inhale air into the reservoir. As the pump is released and the ram/piston retracts oil returns to the reservoir and needs to exhale air. These plastic plugs are constantly clogged, cross threaded, missing and ruin the performance of the pump.
We supply a metal AIR VENT with a steel valve burled head. Simple stupid; using the pump turn burled head out (loosen counter clockwise), transporting pump, turn brass burled head down tight (Right clockwise).
Cast aluminum reservoir:
There are many brands that still use plastic reservoirs and housings for these style pumps. Well; we all know this is a foot pump so it used / placed on the floor. So it is dragged and dropped constantly.
We supply a cast aluminum reservoir that takes a beating! This is a solid base. It resists corrosion and will not crack or split.
【Wide application】 Air hydraulic pump Max. hydraulic pressure is 10000PSI, the product is designed for single-action cylinder, can be widely used in automotive construction, maintenance, machinery and equipment workforce.
【Sturdy and durable】The pneumatic hydraulic foot pump is made of high quality structure, which is durable and can be used for a long time. At the same time, it is easy to maintain and does not require frequent replacement of parts. It has a built in safety overload pump saver to protect hydraulic system components from being affected by air pressure.
【Smooth operation】 Air hydraulic foot pump is designed with pedal function. It can control air and valve by hand or foot operation, which can make your operation more effortless. In addition, the rotary connection simplifies the hydraulic connection and operation.
【Not easy to damage】 Air hydraulic pump has aluminum piston sleeve and aluminum tank, with proprietary anti-corrosion coating, longer service life, durable and not easy to damage, ideal for use in industrial applications.
